HQZ-220L Pneumatic Drill Rig

  • Factory direct
  • One-year warranty
Drilling depth: 220m
Drilling diameter: 130-254mm
Engine Power: 60Kw
Product Detail

Crazy Engineering Days Sale, Submit Form to Get Order Discount and Off Coupon




modelHQZ-220L
tower3m
ChassisRubber track            /           Steel  track/
Drilling diameter130-254mm
Drilling depth220m
One-time advancement length3.6m
Walking speed2.5km/h
Maximum gradeability30
/
Engine brandYunnei/
Engine power60kw
working pressure1.45-2.5mpa
Air consumption17-31m³/min
Drill pipe diameter76/89mm
Drill pipe length1.5/2.0/3.0m
Lifting power15T
Swing speed45-65rpm
Rotating torque4000-4600N.m
Dimensions3800*1700*2250      /       3500*1700*2250mm
weight4.5                           /                5T

Due to the continuous updates and advancements in technology, the technical parameters and configurations of products are subject to change at the time of actual delivery. We strive to provide the most up-to-date and accurate information, but it is always recommended to confirm the technical specifications and configurations at the time of placing your order.


Main features:

1. The water well drilling rig is specifically designed to enable drilling in areas with difficult terrain and limited space, allowing users to access challenging locations.

2. Enhanced work stability through increased counterweight, ensuring strong stability during drilling operations.

3. Perfect cooperation between the engine and hydraulic system, resulting in reduced fuel consumption and improved fuel efficiency.

Hengwang water well drilling rigs are built to be durable and highly reliable, providing safe and efficient operation even in the most demanding environments.


The versatility of the rig allows for various applications, including drilling water wells, conducting mineral exploration, geothermal installations, soil surveys, rock coring, and more. It can be conveniently mounted on tracks, skids, or trucks, providing flexibility and ease of transportation.
