Power：132KW
Drilling Diameter:105-450mm
Total Air Consumption:16-75 m³/min
Drilling Diameter:105-450mm
Total Air Consumption:16-75 m³/min
| Model | HW-RC600 |
| Engine | Cummins |
| Power | 132KW |
| Max. Drilling Depth | 500m |
| Drilling Diameter | 105-450mm |
| Working Air Pressure | 1.6-6 MPa |
| Total Air Consumption | 16-75 m³/min |
| Drill Pipe Length | 3m |
| Recommended Drill Pipe Diameter | Φ102/Φ114mm |
| Recommended Dual-Wall Reverse Circulation Pipe | Φ102/Φ114mm |
| Axial Pressure | 7t |
| Lifting Force | 29T |
| Slow Feed Speed | 29 m/min |
| Fast Feed Speed | 33 m/min |
| Max. Rotation Torque | 12600/6000 Nm |
| Max. Rotation Speed | 0-75 r/min; 0-150 r/min |
| Auxiliary Winch Capacity | 2.5T |
| Leg Lifting Height | 1.7m |
| Drilling Efficiency | 10-35 m/h |
| Traveling Speed | 3.5 Km/h |
| Gradability | 21° |
| Machine Weight | 12.5t |
| Dimensions (L×W×H) | 7×2.1×2.8m |
| Suitable Geology | Loose layers & bedrock |
| Drilling Method | Top-drive hydraulic rotation & feed, DTH hammer or mud drilling |
| Compatible Hammers | Medium/High air pressure series |
| Optional Accessories | Mud pump, centrifugal pump, generator, foam pump |
Shandong Hengwang Group Co., Ltd., as one of the top drilling machinery and piling machinery suppliers in China, has 20 years of experience in the production of drilling rigs and piling machines.
Fill in the form to get the latest product parameters and the best price.
