HW3000 Telescopic Loader

HW3000 Telescopic Loader

Telescopic Loader
Direct from Factory One-Year Warranty CE · EPA Certified

Rated Load: 3000Kg
Bucket Capacity: 1.5m³
Rated Power: 85Kw

Direct WhatsAppReply in under 1 hour
E-mailevan@hengwang.cn
QuoteWithin 24–48 hours
Strength and Certifications

Certified Quality, Factory-Backed

In-house production with a dedicated bulldozer line and international certifications that protect your investment.

Hengwang production line and certifications

Every "HW3000 Telescopic Loader" is built in our 300,000 ㎡ plant, with rigorous quality control at every stage: cutting, welding, assembly and in-line testing. In addition, the high-performance engine and high-efficiency hydraulic system comply with the industry's strictest emission and safety standards, ensuring reliable performance, low fuel consumption and safe operation even in the harshest conditions.

CE Certification
EAC Certification
ISO Certification
EPA Euro Five
Invention Patent
Design Patent
Product Description

HW3000 Telescopic Loader

The telescopic boom loader is to make the two booms of the forklift into a form that can be extended.

When needed, the forklift arm will extend to complete the work that the original forklift arm length cannot reach. When the forklift is not needed The arm retracts to its normal length to facilitate normal work and use.

It is suitable for different sites and different industries, instead of labor, and its compactness makes it a true partner for narrow site operations.


HW3000 Telescopic Loader
1.Main technical specification
Bucket Capacity(m³)1.5
Operating Weight(kg)7600
Bucket Width(mm)2300
Bucket typeHeavy-duty bolt on teeth
Rated Load(kg)3000kg (including attachment or bucket)
Wheel base(mm)2430
Track(mm)1700
Driving ModeHydraulic converter, four wheel drive
Overall Dimensions(mm)LxWxH:6860x2300x2860
Lifting to bucket hinge pin Height(mm)5300
2.Engine Details
ModelYUCHAI Engine
Engine TypeIn-line arrangement, water-cooled, four-cycle diesel,turbocharged Engine
Rated Power(kw)85
Rated Speed (rpm)r/p.min
Optional EngineWEICHAI / CUMMINS / YUNNEI
3.Transmission System
Hydraulic converter + gearbox+drive shaft + hub reduction axles
4.Operating Specifications
Steering SystemArticulated Frame with hydraulic power steering
Min Turning Radius(mm)5800
Driving SystemHydraulic converter, four wheel drive
European quick coupling system
Joystick control
5.Brake System
Service BrakeSafer air assist disc brake braking system
Parking BrakeHand operated(Disc brakes)
6.Tire
Model:16/70-24
Width(mm)410
Diameter(mm)1175
Optional Model17.5-25


Specifications may be adjusted according to configuration. Please consult our team for the OEM/ODM customized version.
